New Holland W50C, W60C, W70C, W80C Tier 4B Compact Wheel Loader Service Manual
New Holland W50C, W60C, W70C, W80C Tier 4B Compact Wheel Loader Service Manual. PDF/USB version is searchable and printable. Printed version is brand new in shrink wrap and will require a binder (not included). Operator's Manuals are bound and do not require a binder. A Service Manual (sometimes referred to as a Repair, Technical, Workshop or Shop Manual) is often large and broken down in to sections for different parts of your equipment. Service manuals cover absolutely every aspect of your machine unless mentioned otherwise.
Sometimes, the engine is covered in a separate service manual that is written specifically for the engine. Most of the time though, it's included in the main service manual.
A service manual will arm you with the same exact information that your local service center has and includes electrical and hydraulic diagrams and which are usually color and or large foldout pages. Most OEM service manuals will also include troubleshooting flow charts, error codes and exploded views of components which are a great help for disassembly and re-assembly. An Operator's Manual typically describes basic equipment operation and maintenance. A Parts Catalog is often large and broken down in to sections for different parts of your equipment. Parts Catalogs cover absolutely every aspect of your machine unless mentioned otherwise.Sometimes, the engine is covered in a separate parts catalog that is written specifically for the engine. Most of the time though, it's included in the main parts catalog. A parts catalog will arm you with the same exact information that your local service center has and includes exploded views of assemblies that are a great help with disassembly and re-assembly. Parts catalogs also include all part numbers for every part of your machine which makes for easy ordering of parts.
Some of the printed versions of the older manuals won't have a good print quality, but most are fine. Engine and crankcase - 001. Powershift transmission external controls - 135. Front axle system - 25. Powered front axle - 100.
Front bevel gear set and differential - 102. Final drive hub, steering knuckles, and shafts - 108. Rear axle system - 27. Powered rear axle - 100.
Rear bevel gear set and differential - 106. Planetary and final drives - 120. Final drive hub, steering knuckles, and shafts - 124. Brakes and controls - 33. Hydraulic service brakes - 202. Parking brake or parking lock - 110. Front axle brake - 204. Reservoir, cooler, and filters - 300. Fixed displacement pump - 104. Variable displacement pump - 106. Main control valve - 359. High flow hydraulics - 600. Hydraulic travel system - 353. Front loader arm hydraulic system - 701. Front loader bucket hydraulic system - 723. Tool quick coupler hydraulic system - 734. Frames and ballasting - 39. Ballasts and supports - 140. Hydraulic control components - 200. Harnesses and connectors - 100. Front axle control system - 045. Warning indicators, alarms, and instruments - 408.Platform, cab, bodywork, and decals - 90.
